The offroad alpine yarder

Combi-Yarder

Versatility redefined - from KONRAD Forsttechnik.

Suspension Cable 500 m
Tower height 11 m
Pulling force 500 m
Pulling force 80+ kN

The offroad alpine yarder

Advantages of the Combi-Yarder

  • Off-road mobility through crawler tracks
  • Fast and safe rigging up
  • Simple operation
  • Simultaneous operation of cable yarder and harvesting head
  • Universal use
  • Big tower height
  • Cable crane detachable
  • Comfortable and safe working place
  • Optional with telescope arm
  • Can be fitted on all excavator models

Combi-Yarder

Technical Data

  Combi – Yarder 2500 Combi – Yarder 3500
Skyline 500m/18mm 500/20mm
Pulling force 80kN 100kN
Mainline 500m/10mm 500m/11mm
Pulling force 25kN 35kN
Guy lines 4x 16mm/70m 4x 18mm/70m
Tower height 11m
Base machine Comp.  Kettenbagger 16 – 24t
Control System Konrad KFS 16
